Specifications
Travels
X: 120"
Y: 60"
Z: 3"
Workpiece maximum weight: 1,587 lbs.
Maximum Speeds: 3,346 inches per minute
Main Supply: 460 V / 60 Hz
Connected Load: 26.0 kVA
Control Voltage: 24VDC
Full Load Current: 32 A
Air Connection: 100 - 175 PSI
Nitrogen Supply N2: 390 PSI
Oxygen Supply O2: 210 PSI
Dimensions
Length: 307"
Width: 111"
Height: 115"
Resonator
Engine (resonator): TruDisk 3001
Maximum Laser Output: 3000 Watts
Cutting Capacities:
Mild steel: 20 mm (0.78")
Stainless steel: 16 mm (0.62")
Aluminum: 12 mm (0.47")
Copper: 4 mm (0.15")
Brass: 4 mm (0.15")
Equipped with
CNC control: Siemens
Chiller
Dust Collector
Shuttle tables
