Specifications
Travels
X axis: 49.6"
Y axis: 49.6"
Z axis: 1.4"
Beam Delivery System: Flying optics
Maximum Axis Speed
X, Y 1181"/min (30 m/min)
Z, 590"/min (15 m/min)
Rated Laser Output: 2000 watts
Peak Pulse Power: 2700 watts
Maximum Sheet Size: 4' x 4'
Maximum Load Weight: 176 lbs.
Maximum Material Thickness
Carbon Steel: .500"
Stainless Steel: .187"
Aluminum: .125"
Dimensions
Machine Weight: 8,488 lbs
Approximate Dimensions: 122" L x 86" W x 65" H
Equipped with
Fanuc 160iL control
Ball screw drives
Chiller
Dust Collector
Features and Advantages
Compact design
Lower running cost
One piece construction-frame and table
