Specifications:
Tonnage Capacity:............................................ 66 Tons
Overall Length of Bed & Ram:......................... 78" (6' 6")
Distance Between Housings:.......................... 59" (4' 11")
Stroke Length (Adjustable):............................ 4"
Open Height:.............................................. 12"
Throat Depth:............................................. 16"
Speed - Approach:........................................... 1.77" / Sec.
- Press:............................................. 0.47" / Sec.
- Return:............................................. 2.76" / Sec.
Motor:............................................. 4.8 Kw 3/60
Overall Dimensions (Approx.):........................113"L-R x 64" F-B x 76" H
Weight (Est.):.............................................. 6280 Lbs.
